Three phase · maximum current380–415 V · 3N · 50 Hz13.5 A
Rated power input
5.5 kW
Maximum power input
7.5 kW
Refrigerant and charge
R410A · 4500 g
Maximum working pressure
4.15 / 2.8 MPa
High / suction side
Protection class
Class I · IPX4
Ambient range
−10 to 43°C
Sound pressure
≤ 58 dB(A) @ 1 m
Compressor type
Twin-rotary DC inverter
Fan
DC motor · horizontal discharge
Net weight
108 kg
System integration
Higher capacity within an integrated system
SK30 is integrated with a water circuit designed for the project load, whether serving underfloor-heating circuits or suitable fan-coil units. Actual performance depends on temperatures, flow, hydraulic design and control strategy.
HYDRONIC SYSTEM · APPLICATION
R410A SK22 / SK30 · DIMENSIONS
Site planning
Dimensions and installation space
1140 × 470 × 1270 mm
The SK30 enclosure measures 1140 mm wide, 470 mm deep and 1270 mm high. The unit needs a planned location that preserves airflow and service access.
Control and support
Scheduling and Wi-Fi connectivity
SK30 provides an LCD interface for operating, water-temperature and time settings, with Wi-Fi connection through the Smart Life app. Final functions depend on the fitted unit and controller configuration.
LCD control interface
Time and schedule settings
Wi-Fi through Smart Life
